Description Solplanet ASW800S-S2
Solplanet ASW800S-S2 hybrid inverter – a compact solution for energy independence
Solplanet ASW800S-S2 is a hybrid single-phase solar inverter with a capacity of 800 W. The device works with solar panels, batteries and the grid. It provides stable power for household appliances.
Reliable conversion technology
The inverter works according to a sine wave algorithm. It generates a clean voltage without distortion. This prevents overheating and damage to the electronics.
Automatic switching of energy sources
The device independently chooses between the grid, solar panels and battery. It reduces electricity consumption by using renewable energy.
Battery compatibility
The inverter supports operation with LiPoFe4 , Li-Ion batteries. This allows you to accumulate energy for autonomous operation.
High work efficiency
The device has an efficiency of 97.6%. This reduces energy loss during conversion.
Protection and security
The inverter has multi-level protection against overvoltage, short circuits and overloads. It operates stably even with unstable mains voltage.
Easy connection and control
The device is controlled and monitored by a mobile application, which also provides energy monitoring.
Solplanet ASW800S-S2 is the optimal solution for energy independence. It saves resources and protects your equipment. This inverter is unlikely to be used in solar power plants, but it is ideal for uninterruptible power supply systems of low power.
Characteristics Solplanet ASW800S-S2
AC connection
Plug-in connector
All-pole sensitive residual current monitoring unit
✓
Certificates and approvals (more available on request)
CE / IEC62109-1 / IEC62109-2 / VDE-AR-N 4105:2018
Climatic category (according to IEC 60721-3-4)
4K4H
Direct current connection
Plug-in connector
Idling power
< 1W.
Installation type
Wall bracket
Maximum efficiency / European efficiency
97.2% / 96.5%
Connection
Communication interface
RS485/Wi-Fi
General characteristics
Number of phases
1
Power
800 W
Producing country
China
Topology
Bare
Manufacturer
Solplanet
Physical properties
Depth
97 mm.
Height
218 mm.
Weight
3.9 kg.
Width
288 mm.
Technical capabilities
Cooling concept
Natural convection
DC switch
✓
Earth fault monitoring / network monitoring
✓
LED indicators (status / fault / communication)
✓
Management
Mobile application
Night monitoring
✓
Overvoltage protection
III type
Possibility of integration with third-party automation systems
✓
Terms of use
Maximum permissible value of relative humidity (without condensation)
100%
Maximum working height
3000 m.
Operating temperature range
-25°C...+60°C
Вихідні параметри по змінному струму
AC mains frequency/range
50Hz/45Hz. up to 55 Hz.
Adjustable power factor range
0.8 leads to 0.8 lags behind
Allowed range of alternating voltage
from 180V. up to 260V.
Harmonic distortion (THD) at rated power
< 3%
Maximum output current
3.5A.
Maximum peak power
800 VA.
Nominal AC voltage
230V.
Rated full power
800 VA.
Rated output current
3.5A.
Вхідні параметри по постійному струму
Maximum input voltage
500V.
Maximum operating input current
16A.
Maximum short-circuit current
20A.
Minimum input voltage
30V.
MPP voltage range
35V. up to 420V. / 360V.
MPP voltage range at full load
65 - 400V.
Number of independent MPPT inputs / lines per MPPT input
1
Starting voltage
35V.
Захист
DC reverse polarity protection / short circuit protection
✓
Degree of protection (according to IEC 60529)
IP66
Protection against jumps
✓
Protection class (according to IEC 62109-1) / overvoltage category (according to IEC 6
I/AC: III; DC: II
