Solplanet ASW5000H-S2 - single-phase, hybrid inverter 5 кВт

CL-0000078
54 00000
Availability: On backorder
14 days
Our advantages
Delivery terms and cost
Payment options

Description Solplanet ASW5000H-S2

Solplanet ASW5000H-S2 is a single-phase, hybrid inverter

The Solplanet ASW5000H-S2 inverter is a reliable solution for stable energy supply. It provides uninterrupted power. If the electricity fails, the inverter switches to batteries. This happens automatically. Your appliances continue to work. The inverter will not let you run out of electricity.

Solplanet ASW5000H-S2 saves you money. During the day, energy comes from solar panels. Excess is stored in batteries. You use it at night. This reduces dependence on traditional electricity.

Two independent MPPT trackers help the inverter work efficiently. The panels produce maximum energy. Even under different lighting conditions. An intelligent system manages energy consumption. This allows you to use every watt to the fullest.

The inverter works well with the mains. It switches instantly in case of failures. Power of 5000 W provides power for the whole house. Solplanet ASW5000H-S2 is a reliable power source. It is suitable for homes and small businesses.

Solplanet ASW5000H-S2 is easy to install. It only requires basic tools. It is mounted on the wall, occupying a minimum of space. Its design is compact and practical. The inverter is suitable for outdoor use. The degree of protection IP66 allows the inverter to work in any weather. But its installation must be under cover. And prevent direct ingress of moisture. The inverter works quietly. The noise level does not exceed 30dB. This makes it suitable for residential installation.

Controlling the inverter is simple - through a mobile application. You can monitor its operation in real time remotely. Connection via Wi-Fi or LAN makes the system convenient and understandable. The manufacturer offers API access for integrating the inverter into third-party automation systems

The inverter also has a backup power supply ( UPS ) function. This means that even during sudden outages, you will not be left without power. It switches in less than 10ms. This ensures that the operation of your appliances will not be interrupted.

Characteristics Solplanet ASW5000H-S2

AC connection
Plug-in connector
All-pole sensitive residual current monitoring unit
Battery type
LiFePO4
Battery voltage range
from 40V. up to 60V.
Certificates and approvals (more available on request)
CE, IEC62109, IEC61000, EN50549, AS/NZS 4777, C10/C11, IEC61727, IEC62116, IEC61683
Climatic category (according to IEC 60721-3-4)
4K4H
Communication with BMS
Compatible battery
Aiswei Ai-LB3 series
Direct current connection
Plug-in connector
Guarantee
10 years
Idling power
< 10Вт.
Installation type
Wall bracket
Max. battery for load efficiency
94.7%
Max. charging / discharging power
5000 W / 5000 W
Max. charging current / Max. discharge current
100A / 100A
Max. input current from the network
27.3A
Max. switching time
≤ 10 ms
Maximum efficiency / European efficiency
97% / 97.6%
Maximum total output power
7500 VA, 10s
MPPT efficiency
99.9%
Noise level (typical)
30dBA
Nominal battery voltage
48B.
Nominal current (at 230 V) / Max. output current
21.7A
Nominal full power / Max. input full power from the grid
6000 VA
Nominal input current from the network
26.1A
Nominal network voltage
230V alternating current
Power factor at nominal power / adjustable volume
7500 Wp STC
Connection
Communication interface
RS485/Wi-Fi/LAN/DRM
General characteristics
Number of phases
1
Power
5 кВт
Producing country
China
Topology
Bare
Manufacturer
Solplanet
Physical properties
Depth
193.5 мм.
Height
455 мм.
Weight
25.1 кг.
Width
483 мм.
Technical capabilities
Cooling concept
Natural convection
DC switch
Earth fault monitoring / network monitoring
LED indicators (status / fault / communication)
Management
Mobile application
Night monitoring
Overvoltage protection
III type
Possibility of integration with third-party automation systems
Terms of use
Maximum permissible value of relative humidity (without condensation)
100%
Maximum working height
3000 m.
Operating temperature range
-25°C...+60°C
Вихідні параметри по змінному струму
AC mains frequency/range
50 Гц±5 Гц / 60 Гц±5 Гц
Adjustable power factor range
≥0,99 / 0,8, що призводить до відставання на 0,8
Allowed range of alternating voltage
від 180В. до 290В.
Harmonic distortion (THD) at rated power
< 3%
Maximum output current
22.7A.
Maximum peak power
5000ВА.
Nominal AC voltage
180В. до 280В. / 230В.
Rated full power
5000ВА.
Rated output current
21.7A.
Вхідні параметри по постійному струму
Maximum input voltage
550В.
Maximum operating input current
16A.
Maximum short-circuit current
20A.
Minimum input voltage
40В.
MPP voltage range
40В. до 530В. / 380В.
MPP voltage range at full load
65 - 400V.
Number of independent MPPT inputs / lines per MPPT input
2/1
Starting voltage
50В.
Захист
DC reverse polarity protection / short circuit protection
Degree of protection (according to IEC 60529)
IP65
Protection against jumps
Protection class (according to IEC 62109-1) / overvoltage category (according to IEC 6
I/AC: III; DC: II
