Reolink RLC-81MA (P330M) - PoE IP camera
Please sign in so that we can notify you about a reply
Description Reolink RLC-81MA (P330M)
IP camera Reolink RLC-81MA (P330M) - is an 8-megapixel video surveillance device with two lenses. Which have different focal lengths, which allows you to broadcast and record two images simultaneously - a general plan and a close-up. RLC-81MA in terms of its operating principle and functionality resembles the legendary camera from Reolink - TrackMIX , but it is not robotic, so it shoots exclusively in a stationary position.
In all other respects, the Reolink RLC-81MA (P330M) model repeats the capabilities of TrackMIX . This includes recognition of moving objects (people, cars and animals), the ability to record a video stream to various media, and the resolution of the lens matrices. So we can consider the RLC-81MA to be a budget version of TrackMIX .
Application
Reolink RLC-81MA (P330M) is installed mainly in places where static monitoring of a certain object is required. As already described above, the camera has two lenses. One with a focal length of f=2.8 mm, the other - 8 mm. The first one shows the general picture, the image transmits dynamic information through which it is clear who moved where. The second one allows you to zoom in on the object and thereby detail it. Thus, thanks to this camera, the operator can get more information, namely: the general situation and such details as clothing, face.
Management
Like all Reolink products, the RLC-81MA is controlled by a convenient mobile application. With the help of the latter, you can monitor the situation in real time and view recordings. The application is ported to various devices and is cross-platform. It works on Windows , MacOs operating systems and has a browser version for web access to the camera.
Video recording
Reolink RLC-81MA (P330M) supports several methods of storing information - on microSD , in the Reolink cloud, on the recorder and on a remote server using different data transfer protocols. Each of these methods has its own advantages and disadvantages. For example: in the case of using microSD , the information disappears with the camera if it is stolen or severely damaged. In the case of using external storage media, the information will remain on it, but then the camera ceases to be an independent and network-independent device and requires additional capital investments.
Integration
Reolink RLC-81MA easily integrates into third-party systems. Such as the personal assistant Google Assistant and the home automation system Home Assistant . If Google Assistant is integrated into the camera by default out of the box, then the camera is integrated into Home Assistant using Reolink integration. Similarly, the camera is combined with other smart home control systems. Such as OpenHub , Domoticz , MajorDomo , etc.
Conclusions
The Reolink RLC-81MA IP camera is a successful solution for monitoring objects that require detail at a long distance - 30 - 50m.
Characteristics Reolink RLC-81MA (P330M)
Compression format
H.264
Effective backlight distance
30 m.
Frame rate
Max. 20 frames per second
Number of backlight diodes
1
Connection
Communication channels
Ethernet
Data transfer protocols
HTTPS, SSL, TCP/IP, UDP, HTTP, IPv4, UPnP, RTSP, RTMP, SMTP, NTP, DHCP, DNS, DDNS, FTP, P2P
Feeding
Current consumption
2A
Power
12 watts.
Supply voltage
12 V. (PoE 48v.)
General characteristics
Appointment
for indoor and outdoor installation
Construction
Cylindrical
Country of origin
People's Republic of China
Guarantee
12 months
Version
PoE
Manufacturer
Reolink
Notification
Notification types
Push, Email
Physical properties
Color
White
Height
67 мм.
Length
178 мм.
Number of lenses
2
Performance material
Aluminum
Weight
460 г
Width
67 мм.
Technical capabilities
Automatic tracking
NO!
Car detection
✓
Continuous recording
✓
Detection of animals
✓
FTP
✓
Identifying people
✓
Integration with Home Assistant
✓
Integration with third-party systems
Onvif
Intercom mode (two-way audio communication)
✓
Microphone
✓
Motion detection
✓
Remote access and notifications
✓
RTSP
✓
SD card support
✓
SD card volume
up to 256 Gb
Support for cloud technologies
✓
Supported operating systems
Windows, MacOs, iOS, Android
The number of infrared diodes
2 pcs. 850 nm
Works with Reolink IoT devices
✓
Works with Reolink PoE NVR
✓
Terms of use
Operating temperature range
-10°C ~ +55°C (14°F ~ 131°F)
Protection class
IP66
Recommended application scenarios
Room, courtyard, shop, office, restaurant, etc.
Оптичні характеристики
Detection angle
Horizontal — 80° Vertical — 42°
Focal length
f=2.8 - 8 mm, zoom module
Resolution
8 MP 3840*2160 4K
Sensor
1/2.7" CMOS Sensor
| CODE | Version | Color | Availability | Price | ||
|---|---|---|---|---|---|---|
|
CL-0000084
|
Availability:
4 item(s)
|
5 00000 ₴ |
